System Format
2-way (3 driver)
Frequency Response (-6 dB)
70 Hz – 25 kHz
Sensitivity (1W@1M)
88 dB
Nominal Impedance
4 ohms
Minimum Impedance
3.8 ohms @ 240 Hz
Maximum SPL
108 dBA (each)
Power Handling (RMS)
100 W
Recommended Amplifier Requirements
25 – 100 W
Bass Alignment
Sealed cabinet
Crossover Frequency
2.5 kHz
Connection
Gold plated push terminals – attached to bracket
Environmental Protection Rating
IP55 -25° to 65° C / -13° to 149° F
Bracket Pivot Angle
Wall: 25 degrees. Wedge: Additional 32.5. Total Max: 45.
Drive Unit Complement
2 x 4" Drivers featuring C-CAM metal cone technology
25 mm (1") C-CAM dome tweeter
Dimensions (H x W x D)
336 x 243.2 x 150 mm (131/4 x 99/16 57/8")
Weight
2.55 kg (5 lb 10 oz)
Finishes
Black or White (Signal White, RAL 9003)
Sold As
Single Unit
If you're looking for a Multibuy saving deal on 3 or more items, we can usually offer you a discount on our already competitive prices.
Simply click the Multibuy Saving button on any product page to build up your list of required products. Once you have built your list, please confirm your required quantities, complete your details and click the "Request Quote" button.
We will contact you by telephone or email within 48 hours to advise you of our best price.
Click the "Add this product" button to add this item to your list and we'll get back to you within 24 hours. Alternatively, please email us on [email protected].
