Frequency Response (-6 dB)
100 Hz – 30 kHz sealed ‘CP’ (85 Hz – 30 kHz –open back)
Nominal Impedance
8 ohms
Sensitivity (1W@1M)
86 dB
Maximum SPL
103.8 dBA
Power Handling (RMS)
40 Watts – Full range (60 watts with crossover set to 100 Hz @ 12 dB/Octave)
Recommended Amplifier Requirements
10 - 60 W
Drive Unit Complement
3 x 3" C-CAM cone bass-mid drivers
1 x 19 mm (3/4") C-CAM Gold Dome tweeter
Crossover Recommendation
100 Hz at a minimum of 12 dB/Octave (24 dB/Octave optimum)
Connection
Gold Plated Sprung push terminals – for bare wire connection up to 4 mm(2)
Overall Diameter (Including Grille)
250 mm (913/16")
Overall Depth (Including Grille)
54 mm (21/8")
Cut-Out Hole Diameter
211 mm (81/4")
Mounting Depth
50 mm (2")
Optional Square Grille - Outer Dimensions
249 x 249 mm (9 3/16")
Fixing Type
3 position Tri-Grip dog leg fixings
Construction Material
ABS (UL94 rated, RoHS2 Compliant) – Painted steel grille
Weight
2.88 kg (6 lb 5 oz)
Pre-Construction Bracket
Sold As
Single Unit
If you're looking for a Multibuy saving deal on 3 or more items, we can usually offer you a discount on our already competitive prices.
Simply click the Multibuy Saving button on any product page to build up your list of required products. Once you have built your list, please confirm your required quantities, complete your details and click the "Request Quote" button.
We will contact you by telephone or email within 48 hours to advise you of our best price.
Click the "Add this product" button to add this item to your list and we'll get back to you within 24 hours. Alternatively, please email us on [email protected].
