System Format
2–Way
2–Way
Channels
1 (Mono)
2 (Stereo)
1 (Mono)
2 (Stereo)
Frequency Response, Installed (-6dB)
35 Hz – 30 kHz?
35 Hz – 30 kHz?
Nominal Impedance
4 Ohm (Mono)
8 Ohm (Stereo)
4 Ohm (Mono)
8 Ohm (Stereo)
Minimum Impedance (20Hz to 20kHz)
3.4 Ohm @ 15 kHz (Mono)
6.8 Ohm @ 15 kHz (Stereo)
3.4 Ohm @ 15 kHz (Mono)
6.8 Ohm @ 15 kHz (Stereo)
Sensitivity (2.83Vrms@1m, Installed)
86 dB
86 dB
Maximum Peak SPL* (single speaker @ 1m Z-Weighted)
(Mono) 114 dB
(Mono) 114 dB
Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)
150 W (Mono)
2 x 75 W (Stereo)
150 W (Mono)
2 x 75 W (Stereo)
Recommended Amplifier Power (RMS into 8 OHM, Music Signal)
40 – 150 W (Mono)
2 x 20 – 75 W (Stereo)
40 – 150 W (Mono)
2 x 20 – 75 W (Stereo)
Drive Unit Complement
1 x 7" (178 mm) RST II dual-coil bass driver
2 x 1" (25 mm) C-CAM tweeter
1 x 7" (178 mm) RST II dual-coil bass driver
2 x 1" (25 mm) C-CAM tweeter
Crossover Frequency
LF/HF: 2.25 kHz
LF/HF: 2.25 kHz
Mounting Depth
99 mm (37/8")
99 mm (37/8")
Cut-Out Hole Diameter
212 mm (83/8")
212 mm (83/8")
External Dimensions (Including Grille (H x W x D))
242 x 242 x 103? mm (91/2 x 91/2 x 44/16")
242 x 242 x 103? mm (91/2 x 91/2 x 44/16")
Weight (each)
2.1 kg (4 lb 10 oz)
2.1 kg (4 lb 10 oz)
Pre-Construction Bracket
CM-B
CM-B
Cabinet Finish
Matte black & Orange? & Bronze
Matte black & Orange? & Bronze
Sold As
Single Unit with CM-Round Grille (white)
Single Unit with CM-Round Grille (white)
Corner Switch
On/Off
On/Off
HF Switch
- /0/ +
- /0/ +
Music/Movie Switch
Music/Movie
Music/Movie
Mono/Stereo Switch
Mono/Stereo
Mono/Stereo
Warranty
Lifetime
Lifetime
