THX Certification

THX® Certified Ultra

System Format

3 Way

Sensitivity (2.83 Vrms @ 1 M)

90 dB

Maximum Linear SPL**** (@1m, free space)

Continuous 109 dB, Peak 122 dB

Power Handling (RMS)

Continuous 350 W, Peak* 1400 W

Nominal Impedance

4 Ohms

Minimum Impedance (20 Hz - 20 kHz)

3.8 Ohms

Recommended Low Frequency Crossover Frequency

40 - 80 Hz (High Pass)

Recommended Amp Requirements (RMS)

200 - 1400 W (IA750-2 or IA750-4)

Bass Alignment

Ported**

Port Tuning Frequency

38 Hz**

LF Extension, In Wall, With Port Bungs (- 6dB)

42 Hz

LF Extension, In Free Space, No Port Bungs (- 6dB)

42 Hz

HF Extension (-6dB)

>30 kHz

Drive Unit Complement

2 x 8" RDT Driver
2 x 2.5" C-CAM Driver
1 x MPD Transducer

External Dimensions (Cabinet Only (H x W x D))

1080 x 300 x 240 mm (421/2 x 1113/16 x 97/16")

External Dimensions (Inc Grille) (H x W x D)

1080 x 300 x 253.6 mm (421/2 x 1113/16 x 10")

Max External Dimensions (Inc all Fittings) (H x W x D)

1132 x 438 x 253.6 mm (449/16 x 171/4 x 10")

Weight

40.4 kg (88 lb 14 oz)

Conditions

* Calculated from a peak voltage, this is not a true power figure but useful for comparisons.

** When used in an In-Wall or On-Wall configuration it is recommended to use the fitted port bungs to control bass output. This will effectively make the product a sealed box.

*** Band limited with Low pass at 200 Hz, should only be used with IA800-2C and the correct speaker profile.

**** Tested with a music like noise signal with distortion and power compression remaining below audible limits.

THX

THX® Certified Loudspeakers.

THX® and the THX® Logo are the property of THX® Ltd., registered in the U.S. and other countries.
