Model

-          Coda W

Drive units

-          Uni-Q Driver Array:

-          HF: 25 mm (1 in.) aluminium dome

-          LF/MF: 130 mm (5.25 in.) magnesium/aluminium alloy cone

Frequency range (-6dB) measured at 85dB/1m

-          38 Hz- 20 kHz

-          *Depends on EQ settings

Frequency response (±3dB) measured at 85dB/1m

-          41 Hz - 20 kHz

-          *Depends on EQ settings

Amplifier output power (per speaker)

-          LF: 70W HF: 30W

Amplifier class (per speaker)

-          LF: Class D HF: Class D

Max SPL measured at 1m

-          102 dB

Wireless streaming features

-          Bluetooth 5.4, aptX Adaptive™, aptX Lossless™

Source resolution

-          Optical up to 96kHz/24bit

-          USB Type-C up to 192kHz/24bit

-          HDMI up to 1.411 Mbps PCM

-          *Depends on source resolution

Interspeaker connection

-          Wired: all sources resampled to 96kHz/24bit PCM

Dimensions (HWD per speaker)

-          285 x 168 x 268 (11.2 x 6.6 x 10.55 in.)

Weight (per set)

-          11.3 kg (24.9 lbs)

Power input

-          100 – 240VAC 50/60Hz

Power consumption

-          200W (operating power)

-          <0.5W (standby power)

Primary speaker

-          Inputs HDMI ARC

-          Optical

-          USB Type-C

-          RCA (LINE)

-          RCA (PHONO)

-          USB Type-C (interspeaker)

Secondary speaker

-          USB Type-C (interspeaker)

Output RCA

-          Subwoofer output

-          USB Type-C (interspeaker)

-          USB Type-C (5V DC)

Finishes

-          Vintage Burgundy, Nickel Grey, Moss Green,Midnight Blue, Dark Titanium
