Emotiva RMC-1+ 16 Channel Dolby atmos AV Processor
Specification
Digital Decoding Modes
Dolby Atmos®, Dolby TrueHD, Dolby Digital Plus, Dolby Digital 5.1,
Digital Post Processing Modes
Dolby Surround Upmixer (DSU), Dolby Atmos Height Virtualization,
Audio Operating Modes
Reference Stereo (purist stereo mode), Direct Mode (minimal
Analog Inputs
Digital Inputs
Analog Outputs
Digital Outputs
Dimensions
Dolby Atmos®, Dolby TrueHD, Dolby Digital Plus, Dolby Digital 5.1,
DTS:X™, DTS:X Pro™, DTS-HD Master Audio, DTS-HD High Resolution
Audio, DTS 5.1, PCM-Multi 5.1, PCM-Multi 7.1
Digital Post Processing Modes
Dolby Surround Upmixer (DSU), Dolby Atmos Height Virtualization,
DTS Neural:X upmixer, DTS Virtual:X, IMAX Enhanced (Coming Soon)
Audio Operating Modes
Reference Stereo (purist stereo mode), Direct Mode (minimal
processing; with bass management), Stereo Mode, All Stereo Mode
Analog Inputs
1 pair (stereo) Reference quality analog audio (balanced; XLR); 3 pair
(stereo) Reference quality analog audio (unbalanced; RCA)
Digital Inputs
8 x HDMI 2.1 with Fast Port Switching (FPS), Variable Refresh Rate
(VRR), and Fixed Rate Link (FRL); 4 x Toslink optical S/PDIF digital
audio; 4 x Coax (RCA) electrical S/PDIF digital audio; 1 x AES/EBU
(XLR) digital audio; 2 x USB Type A digital data (for firmware updates
and future enhancements); 1 x USB Type B digital audio (“USB DAC”
input); 1 x Ethernet port (RJ-45); 1 x Wifi antenna
Analog Outputs
16 channels Reference quality main analog audio (balanced XLR); 1
pair (stereo) analog line level Zone 2 output (unbalanced); 1 x high
quality headphone output (1/8” stereo connector)
Digital Outputs
2 x HDMI 2.1; 1 x Toslink optical S/PDIF digital audio; 1 x Coax (RCA)
electrical S/PDIF digital audio; 4 x Independently programmable
Trigger Outputs; 3 x Expansion Ports (for future expansion modules)
Dimensions
W x D x H Unboxed mm with feet: 432 x 394 x 191
Weight: 13.6 kg
Weight: 13.6 kg
